Product Highlights
Additional Features:
- High amperage load up to 50 amps per zone
- Available with temperature cut off
- Simple dial setpoint
- Multiple configurations
- NEMA 4X enclosure
- Easy-view clear plastic door
Menu
Menu
DON'T SEE YOUR SIZE OR OPTION?
HAVE A QUESTION ABOUT WHICH BRISKHEAT PRODUCT IS RIGHT FOR YOU?
NEED PURCHASING ASSISTANCE?
CONTACT US.
WE ARE HERE TO HELP!
Monday - Friday
0900AM - 0500PM
Email Us
online_enquiry@kromax.com
Specifications
Voltage: 120, 240, 277, or 480 VAC with 3-phase option
Maximum Amp Load: Up to 50 amps per zone
Temperature Control Range: 0°F – 150°F, 50°F – 300°F, or 150°F – 650°F
Temperature Display Unit: Dial setpoint °F
Accuracy: ± 5°F (± 3°C)
Hysteresis: 2% of full scale
Sensor: 304 stainless-steel bulb and capillary, 10 ft (3 m) long
Environmental Exposure: Operating range: -40°F to 160°F (-40°C to 71°C)
Enclosure Material: Plastic or stainless steel
Enclosure Dimensions: 5.6 in x 5.2 in x 3.4 in (143 mm x 132 mm x 86 mm)
TB4000 Product Measurements:
Bulb Dimensions:
| Temperature Range | Diameter | Length | ||
| Inches | mm | Inches | mm | |
| 0° to 150°F | 3/8 | 10 | 6 7/8 | 175 |
| 50° to 300°F | 3/8 | 10 | 4 3/8 | 111 |
| 150° to 650°F | 3/8 | 10 | 3 5/8 | 92 |
Resources
Approvals/Certificates
Catalog/Specifications Sheet
Instruction Manuals
| Weight | N/A |
|---|---|
| Voltage | 120, 240, 277, 480 |
| Temperature Control Range | 0F to 150F, 50F to 300F, 150F to 650F |
| Contactors | 1, 2 |
